CAMERA
Angle Adjustment: Pan: 0°to 360°, Tilt: 0°to 180°, Rotate: 0°to 360°
Image Sensor: 2.0 megapixel progressive scan CMOS
Signal System: PAL/NTSC
Min. Illumination: 0.01 Lux@(F1.2, AGC ON), 0 Lux with IR
Shutter Time: PAL: 1/25 s to 1/50, 000 s
NTSC: 1/30 s to 1/50, 000 s
Lens: 2.8 mm, 3.6 mm fixed focal lens
Lens Mount: M12
Day& Night: IR cut filter
Horizontal Resolution: 1920 (H) × 1080 (V)
Video Frame Rate: PAL: 1080p@25fps
NTSC: 1080p@30fps
Synchronization: Internal Synchronization
LENS
Horizontal Field of View: 103°(2.8 mm), 82.2°(3.6 mm)
MENU
White Light: Alarm/Off
D/N Mode: Auto/Color/BW (Black and White)
White Balance: Auto / Manual
BLC: Support
AGC: Yes
HLC: Support
Language: English
Function: Brightness, Sharpness, Mirror, Smart IR
INTERFACE
Video Out: 1 HD analog output
GENERAL
IR Range: Up to 20 m
PIR Range: Angle: 110°, Range:11 m
Material: Metal
Ingress Protection: IP67
Operating Conditions: -40 °C – 60 °C (-40 °F – 140 °F)
Humidity 90% or less (non-condensing)
Power Supply: 12 VDC±25%
Dimension: 68 mm × 70 mm × 179.8 mm ( 2.68″ × 2.76″ × 7.08″ )
Weight: Approx. 358 g (0.79 lb.)
