MikroTik (CRS112-8G-4S-IN) 8x Gigabit Ethernet Smart Switch with 4x SFP Cages

The Mikrotik Cloud Router Switch CRS112-8G-4S-IN is a “small size low cost” member of our CRS series. It comes with eight Gigabit Ethernet ports and four SFP cages.

Our CRS series combines the best features of a fully functional router and a Layer 3 switch, is powered by the familiar RouterOS.

All the specific Switch configuration options are available in a special Switch menu, but if you want, ports can be removed from the switch configuration, and used for routing purposes.

Product Specifications

DETAILS
Product code	CRS112-8G-4S-IN
Architecture	MIPSBE
CPU	QCA8511
CPU core count	1
CPU nominal frequency	400 MHz
Dimensions	200x143x44mm
License level	5
Operating System	RouterOS
Size of RAM	128 MB
Storage size	16 MB
Storage type	FLASH
Tested ambient temperature	-30C to +55C

Powering

DETAILS
Max Power consumption	13.5W
PoE in	Passive PoE
PoE in input Voltage	10-57 V
Number of DC inputs	2 (DC jack, PoE-IN)
DC jack input Voltage	10-57 V

Ethernet

DETAILS
10/100/1000 Ethernet ports	8

Fiber

DETAILS
SFP ports	4

Peripherals

DETAILS
Serial port	RJ45

Other

DETAILS
Current Monitor	Yes
PCB temperature monitor	Yes
Voltage Monitor	Yes
