CAMERA
Image Sensor: 2.0 megapixel progressive scan CMOS
Signal System: PAL/NTSC
Effective Pixels: 1920 (H) × 1080 (V)
Min. Illumination: 0.01 Lux@(F1.2, AGC ON), 0 Lux with IR
Shutter Time: 1/25(1/30) s to 1/50,000 s
Lens: 2.8 – 12 mm @ F1.4
Lens Mount: φ14
Day& Night: IR cut filter with auto switch
Video Frame Rate: PAL: 1080p@25fps
NTSC: 1080p@30fps
HD Video Output: 1 Analog HD output
Synchronization: Internal Synchronization
S/N Ratio: More than 62 dB
GENERAL
Operating Conditions: -40 °C – 60 °C (-40 °F – 140 °F)
Humidity 90% or less (non-condensing)
Power Supply: 12 VDC±15%
Power Consumption: Max. 4 W
IR Range: Up to 40m
Dimension: Φ130.54 × 102.4mm (Φ5.1” × 4”)
Weight: Approx. 710g
