MikroTik RB750Gr3 hEX 5 Port Gigabit Router

MikroTik RB750Gr3 hEX is a five port Gigabit Ethernet router for locations where wireless connectivity is not required. The device has a full size USB port. This new updated revision of the hEX brings several improvements in performance.

It is affordable, small and easy to use, but at the same time comes with a very powerful dual core 880MHz CPU and 256MB RAM, capable of all the advanced configurations that RouterOS supports.

IPsec hardware encryption (~470 Mbps) and The Dude server package is supported, microSD slot on it provides improved r/w speed for file storage and Dude.

Product Specifications

DETAILS
Product code	RB750Gr3
Architecture	MMIPS
CPU	MT7621A
CPU core count	2
CPU nominal frequency	880 MHz
CPU Threads count	4
Dimensions	113x89x28mm
License level	4
Operating System	RouterOS
Size of RAM	256 MB
Storage size	16 MB
Storage type	FLASH
Tested ambient temperature	-30 + 70 C

Powering

DETAILS
Max Power consumption	5W
PoE in	Passive PoE
PoE in input Voltage	8-30 V
Number of DC inputs	2 (DC jack, PoE-IN)
DC jack input Voltage	8-30 V

Ethernet

DETAILS
10/100/1000 Ethernet ports	5

Peripherals

DETAILS
Number of USB ports	1
USB Power Reset	Yes
USB slot type	USB type A
Max USB current (A)	1

Other

DETAILS
PCB temperature monitor	Yes
Voltage Monitor	Yes
